Chemical Curtains – Splash & Acid Resistant
Chemical Splash Curtains
In workspaces that contain large quantities of dangerous chemicals, it’s important to keep employees and property safe from harm and damage. Steel Guard Safety provides high-quality reinforced vinyl chemical splash curtains that effectively block chemicals and acid.
They combine the chemical resistance of PVC or Polyethylene with superior construction to enclose dangerous acids and chemical storage & production. These curtain wall products are customizable to meet your individual project needs. Use them with our Track and Roller System for access to the area.
PVC Chemical splash curtains are inherently resistant to most chemicals. The most common material is transparent PVC, or coated PVC. However, polyethylene is also available for resistance to chemicals that aren’t as effective with PVC. See our Chemical Resistance Chart for full details on which material is most effective.
Chemical curtains block dangerous chemicals in industrial environments such as:
- Sulfuric acid
- Sodium Chloride
- Sodium Hydroxide
- Hydrochloric acid
- Many other chemical compounds (See our chemical resistance chart for more details)
Additional Information:
Use Chemical Splash Curtains in Many Applications
If your facility experiences regular use of chemicals or acids, you need to have curtain walls that effectively avoid any damage they can cause.
Steel Guard’s chemical resistant curtains are commonly used in:
[one_half]
- Chemical processing areas
- Power plants & generation stations
- Hospitals
- Labs & schools
- Chemical mixing plants
- Paint, Primer and Prep Areas[/one_half]
[one_half]
- Chemical factories
- Pharmaceutical facilities & production
- Chemical packaging & dispensing
- Chemical manufacturing separation
- Chemical over spray areas
- Dust Containment and Control
[/one_half]
You can request a quote online or call 1-800-347-8368 to be connected with a sales professional to further discuss your requirements. We will provide additional technical details and help design custom chemical resistant curtain systems to install in your facility.
Chemical Splash Curtains
Standard & Optional Features
2-Wheel Nylon Roller Hooks
Make sliding and folding of the curtain a cinch. 2-wheel steel roller hooks are available for tall curtain systems.
#2 Toothed Brass Grommets
#2 Brass Toothed Grommets are spaced every 12 in. on center of the curtains to hang securely on the roller hooks.
Galvanized Steel Roller Track
Heavy-Duty 16 gage roller track system which modularly connects track lengths to your desired length and shape. (Dim – O.D. – H-1.25″ x W-1.44″)
Track Mounting Hardware
5 Different Mounting Options Available. Including a Universal Mount to use in place for Beam to Chain, Threaded Rod, and Wall Mount. (See Mounting & Hardware)
Velcro Attachments
2 in. Velcro side attachments easily seal and attach both sides of curtains to multiple curtains. Available in standard 2ft x 1ft swatches, full length, or custom.
Chain Weighted Hem
Heavy-Duty 3/16 in Thick Galvanized Chain inserted into the bottom pocket to stabilize the curtain against wind & drafts.
Heat Welded Interior Seams
Interior Seams are Electronically welded with RF Bar Sealers for an Extra tough resistance to tears. Outer Hems are sewn with a heavy-duty double-lock stitched nylon thread.
Vinyl Floor Sweep (Add-On)
Vinyl Floor Sweep – Sewn-on or Velcro Option – Seals bottom 1″ gap to seal off dust, dirt, & contaminants.
Part# CA 300 – Sewn On
Part# CA 299 – Velcro
Floor Mount D Ring Attachments (Add-On)
Floor Mount D-Rings – Included with strap and buckle. Fastens the curtain to the floor protecting against wind & updrafts
Part# CA 101
Adhesive Velcro (Add-On)
2 inch Adhesive Velcro – Attaches any curtain to a brick, metal, concrete, or wood wall or door opening.
Part# CA 677 – 2″ PSA Loop
Part# CA 694 – 2″ PSA Hook
Magnet Attachments (Add-On)
2 in. Magnets Attachments provide a quick and easy attaching and un-attaching of multiple curtains.
Part # CA 550 – Sew On
Part # CA 551 – Adhesive PSA
20 Mil Clear PVC FR - Transparent
Completely Transparent PVC Vinyl Material. 20 Mil Thick or .020 inches. Double Polished for a smooth finish and completely clear viewing. Our most popular PVC Material. The Vinyl Meets Flame Resistant Standards, CFM, NFPA-701 & ASTM E-84. For Tech Specs see 20 mil clear PVC FR Technical Specifications
20 Mil Clear PVC - FR
40 Mil Clear PVC FR - Transparent
Completely Transparent PVC Vinyl Material. 40 Mil Thick or .040 inches. Double Polished for a smooth finish and completely clear viewing. A thicker PVC Curtain Material for Heavier Duty Applications. The Vinyl Meets Flame Resistant Standards, CFM, NFPA-701 & ASTM E-84. For Tech Specs see 40 mil clear PVC FR Technical Specifications
40 MIl Clear PVC - FR
18 oz Coated Vinyl FR - Opaque
18 oz per sq/yd Coated Vinyl provides excellent Tear and Tensile Strength while also giving Superior Abrasion Resistance when Compared to Laminate Vinyls. The Vinyl Meets Flame Resistant Standards, CFM, NFPA-701 & ASTM E-84. Generally used on the top & bottom panels but can also be selected as a complete opaque curtain. For More Information on Tech Specs, See 18 oz FR Coated Vinyl Technical Specifications Here.
Yellow
Red
Orange
Champion Blue
Royal Blue
Purple
White
Black
Tan
Forest Green
THREADED ROD MOUNT - SUSPENDED
Track System is mounted in from beams or trusses with a C-Clamp, and using a 3/8″ Threaded Rod to suspend down to the desired height. The Threaded Rod Track Mounts then slide over the threaded rod. Mount Spacing can be from 4′ -8′ with taller heavier systems over 25′ being 6′ or less usually
TH C600
TH C502
TH C503
TH C601
TH C604 Use w/ 500s
TH C900 - Sub for Threaded Rod, Beam to Chain, & Wall
BEAM TO CHAIN MOUNT - SUSPENDED
Track System is mounted in from beams or trusses with a C-Clamp, and using an S-Hook suspended down with chain to the desired height. The Track Mounts then connect the system with more S-hooks. Aircraft Cable is another option to use instead of chain. Mount Spacing can be from 4′ -8′ with taller heavier systems over 25′ being 6′ or less usually
TH C500
TH C501
TH C503
TH C503
CEILING MOUNT
Ceiling Mount Hardware is attached with lag bolts directly flush to ceiling, floor joists or to steel beams.
TH C200
TH C202
TH C203
TH C201
WALL MOUNT
For the Wall Mount installation method, track mounts are attached to walls above openings, or you can use wall end brackets to brace or stabilize the track.
TH C303
TH C302
TH C301
TH C300
FLOOR MOUNT - FREE STANDING
The Floor Mount System which is Free Standing, uses base plates at intervals anywhere from 4′ – 10′ depending on the height of the curtain system. The base plates attach to posts which connect to the floor mount splices.
TH C800
TH C802
TH C803
TH C801
6' - TH F06, 7' - TH F07
8' - TH F08, 9' - TH F09
10' - TH F10, 12' - TH F12
TH C804
STRAIGHT TRACK, ROLLER HOOKS, & ACCESSORIES
Straight Tracks, Plain Connectors, Universal Mounts, End Stops, as Well as Pulleys to Customize Your Track Curtain System.
TH R101
TH R100
TH C700
4' - TH T04
5' - TH T05
6' - TH T06
7' - TH T07
8' - TH T08
10' - TH T10
12' - TH T12
