Looking to maximize efficiency in your warehouse? Steel Guard’s warehouse partition walls offer a practical solution for managing warehouse floor space effectively. These versatile partition systems are designed to create designated storage areas, helping to streamline storage and retrieval operations while reducing time and costs.
For businesses looking to divide temperature zones, Energy-Shield insulated curtain walls provide a cost-effective solution for freezer-to-freezer, cooler-to-cooler, or freezer-to-ambient spaces. These insulated warehouse partition walls are available with multiple R-values (from R-3 to R-15) to suit your temperature control needs. They are flexible, allowing you to reconfigure or modify them as your cold storage warehouse or manufacturing demands evolve. Additional features include hanging installation from trusses, strip curtains, floor mount straps, and floor sweeps for optimized functionality.
Beyond simple space division, our warehouse partitions are crafted from specialized materials that provide additional benefits. They help prevent the spread of liquids, metal smut, dust, fire, weld sparks, and even chemicals beyond the enclosed areas. This makes them an excellent choice for a safe and well-managed storage environment.
Warehouse Partition Wall Benefits
Whether you need temporary or permanent warehouse partition walls, our solutions include floor-to-ceiling and part-height systems that are reconfigurable and relocatable to adapt to your business’s changing needs.
Benefits of Our Warehouse Partition Wall Systems:
Designed to suit the specific requirements of your warehouse environment, these partitions help you optimize your space while keeping processes streamlined and efficient. From temporary warehouse screens to permanent solutions, our full range of partitions offers the adaptability and durability your business needs.
These insulated curtain walls keep rooms effectively in temperature zones. This can make warehouses space more efficient and the ability to make modular freezer and refrigeration zones for cold storage. The panels are also modular so when a warehouse job is complete they can be put away or reconfigured for a new job. According to the EPA Having a Thermal Insulation System like Industrial Insulated Curtains in the Food Industry reduces energy and costs.
Industrial Insulated Curtain Walls also keep a constant temperature to prevent overheating and needless energy loss. They also block areas off from dust, chemicals, and other possible contaminants. With the installation of insulated curtain walls in place, your facility will ultimately be cleaner and easier to maintain and provide a considerably safer environment for employees and visitors who may require additional protective measures. If you are needing a foldable solution, check out our Foldable Insulated Warehouse Curtains
Warehouse Partition Wall Common Applications
• Refrigerated & freezer areas
• Warehouse separation with temperature controlled space
• Loading dock areas
• Containment for storage and work space
• Food & beverage industry including food processing lines
• 3 PLS (Third Party Logistics)
• Data centers
• Airports
• Garage dividers/separation & insulation
Our sales staff is available Monday through Friday to answer all of your questions about designing Energy Shield insulated curtainwall. Call 1-800-347-8368 to speak with someone today, or use our Request a quote system and a sales professional will contact you within 24 hours.
Energy Shield Insulated Material
Energy Shield Materials – 2 layers of 18 oz coated vinyl sandwiched around 1, 2, or 4 Layers of 3M Thinsulate Ultra. R Values Range from R-3, R-6, and R-9. All Materials meet NFPA-701 and ATM E-84 guidelines for Flame Retardancy in Buildings. See Materials Tab for More Details.
#2 Brass Grommets
#2 Brass Toothed Grommets are spaced every 12″ on center. The curtains can be affixed directly to rafters, or use a Universal L-Channel to affix Panels.
Velcro Side Attachments
2 inch Velcro side attachments are on both sides of the curtain panel to easily seal and attach both sides to multiple curtains to create an infinite length wall.
Floor Sweeps (Add-On)
Velcro attaches to the full length of one run of curtains – Seals bottom of insulated curtain to the floor.
Strip Door Walk/Drive Through (Add-On)
A Vinyl Strip Door can be added for access of Workers or Forklift Traffic between rooms.
Floor Mounts (Add-On)
Floor Mount D-Rings – Included with strap and buckle. Fastens the curtain system to floor.
Part# CA 101
Angle Iron
Energy Shield FT I
2-Layers of 18 oz Coated Vinyl Sandwiched around 1 Layer of Thinsulate 3M Ultra. Meets ASTM E-84 and NFPA-701 Certifications.
Provides Temperature separation of 17 degrees F (9 degrees C). < See Materials Here >
Energy Shield FT II
2-Layers of 18 oz Coated Vinyl Sandwiched around 2 Layer of Thinsulate 3M Ultra. Meets ASTM E-84 and NFPA-701 Certifications.
Provides up to 24°F (13° C) of temperature separation; R-Value of 6.0. < See Materials Here >
